The machine is suitable for single color embroidery, pock attaching, decorative stitching, webbing stitching, label / badge attaching, shoe applications and many more special applications.
Characteristics:
Max. stitching speed is 2,500rpm. achieved high productivity with fast sewing speed and feeding speed;
Large rotating hook;
Liquid crystal touch operation pane;
Applying the same Mitsubishi controlling system;
Automatic thread trimmer;
Versatility of application.
Specification:
|
Model |
FX2516 |
|
Sewing Area |
250 X 160 MM |
|
Thread Size |
Polyester Thread 0.3-1 mm |
|
Rotating Hook |
Large Rotating Hook |
|
Thread Trimmer |
Have |
|
Stitch Length |
100 mm |
|
Pattern Storage |
Below 691 |
|
Stepping Foot Lift |
Max.18mm |
|
Max. Stitches |
8000/Pattern |
|
Work Holder Height |
Standard 25mm (Max. 30mm) |
|
Programmer |
Build in Pattern Programmer |
|
Driving Motor |
Direct Drive Servo Motor |
|
Needle |
DP17X25 |
