| Weight: | 260KGS | Type: | PATTERN SEWING MACHINE |
|---|
Working Video 1: http://www.foxsew.com/company-video/programmable-electronic-pattern-sewing-machine-18.html
Working Video 2: http://www.foxsew.com/company-video/programmable-pattern-sewing-machine-19.html
The machine is suitable for single color embroidery, pock attaching, decorative stitching, webbing stitching, label / badge attaching, shoe applications and many more special applications.
Applications: Car seats, Aero Seats, Boots, Shoes, Shoes Uppers, Footwear, Handbags, Furniture, Car upholstery, Saddles, Luggage, Suitcase, Backpacks, Leather Jackets, Leisure wears, Sportswear, Down clothes, Warm clothes, Jeans, Sofa, and attaching label, widely used for many different industries.
Characteristics:
Max. stitching speed is 2,500rpm. achieved high productivity with fast sewing speed and feeding speed;
Large rotating hook;
Liquid crystal touch operation pane;
Applying the same Mitsubishi controlling system;
Automatic thread trimmer;
Versatility of application.
Specification:
|
Model |
FX2010 |
|
Sewing Area |
200X100 mm |
|
Thread size |
polyester thread 0.3-1mm |
|
Rotating hook |
large rotating hook |
|
Thread trimmer |
Have |
|
Stitch length |
10mm |
|
Pattern storage |
below 691 |
|
Stepping foot lift |
max.18mm |
|
Max. stitches |
8,000/pattern |
|
Work holder height |
standard 25mm(max.30mm) |
|
Programmer |
build in pattern programmer |
|
Driving motor |
direct drive servo motor |
|
Needle |
DP17×25 |
