| Max. Sewing Speed: | 2000 R.p.m | Stitch Length: | 0-9 Mm |
|---|---|---|---|
| Power: | 400W 1400 R.p.m And 550W Servo Motor | Stitch Formation: | Lock Stitch |
| Mechanical Configuration: | Flat-Bed | Type: | Heavy Duty Sewing Machine |
Compound Feed Heavy Duty Lockstitch Sewing Machines series
FX-4400 (Single-needle)
FX-4420 (Double-needle)
FX-4401 (No backstitch)
FX-4400L (Left hook)
FX-4400D (Single-needle and thread trimmer with reverse sewing)
FX-4420D (Double-needles and thread trimmer with reverse sewing)
Features: Compound Feed Heavy Duty Lockstitch Sewing Machine is the latest of FOXSEW brand heavy duty sewing machines, which is designed with large vertical rotating hooks for thread loop catching and sliding bars for thread up-taking. It has been sub-classed into single needle, two needles, single needle with under-trimmer and two needles with under-trimmer. The application of needle bearings for arm shaft and hook shaft, dog belt driving, plunger pump lubrication and compound feed by needle bar, presser foot and feed dog provides this series with such splendid features as smooth running, quiet working and a long service life. It is also equipped with a safety clutch to prevent the hooks from damage by over-duty operation. So it is especially available in stitching car seat cushions, safety belts, safety air bags, tents, parachutes, etc..
Specifications:
|
Model |
FX-4400 |
|
Max. Sewing Speed |
2000 r.p.m |
|
Stitch Length |
0-9 mm |
|
Needle Bar Stroke |
36 mm |
|
Thread Take-up lever stroke |
74.5 mm |
|
Presser foot lift |
By Hand: 8mm By Knee: 16 mm |
|
Needle Size |
DPX17 18#-23# |
|
Rotating Hook |
Automatic Lubricated Large Rotary Hook |
|
Lubrication |
Automatic Lubricated |
|
Safety Clutch device |
Yes |
|
Needle Gauge |
Standard: 6.4mm, 3.2, 4.8, 9.5, 12.7 mm is available. |
|
Motor |
400W 1400 r.p.m and 550W Servo Motor |
